Tensiune: 12 V DC
Putere: 20Wp
Numar Celule: 36
Dimensiune: 440x350x25mm
Durata de livrare: 2-3 zile
| Reduceri de Cantitate | ||||
|---|---|---|---|---|
| De la | Discount | Pret / buc | Economisesti | |
| 3 buc | -10% | 157,03 RON | 52,34 RON | + |
- Descriere
- Caracteristici
- Download (1)
- Review-uri (0)
Este realizat cu 36 de celule din Policristalin si are un randament si eficienta mare de conversie a energiei luminoase avind o putere maxima de 20 W. Celulele sunt laminate intre folii cu transparenta inalta de acetat de vinil (EVA) si sticla securizata asamblate pe un cadru robust, din aluminiu anodizat, prevazut cu 4 gauri pentru instalare rapida. Indeplinesc cele mai stricte cerinte de siguranta pentru inalta tensiune si sunt echipate cu diode de bypass pentru a preveni supraincalzirea si pentru a minimiza pierderea de putere din cauza umbririi. Panourile sunt echipate cu cutii de junctiune fara cabluri si conectori.
Caracteristici:
- Tensiune: 12 V DC
- Putere: 20Wp
- Numar Celule: 36
- Dimensiune: 440x350x25mm
- Tip panou: Policristalin
- Toleranta: - 3% / + 3%
- Tensiunea la puterea maxima VMPP: 18.4 V
- Curentul la puterea maxima IMPP: 1.09 A
- Tensiunea de mers in gol VOC: 21.96 V
- Curentul de scurtcircuit ISC: 1.18 A
- Coeficientul temperatura pentru MPP (%) 0.45/°C
- Coeficientul temperatura pentru VOC (%) 0.35/°C
- Coeficientul temperatura pentru ISC (%) +0.04/°C
- Tensiune maxima sistem: 1000 V
- Interval de temperatura: -40 ° C pana la + 85 ° C
- Suprafata capacitate maxima de incarcare: 200 kg / m²
- Nu contine cablu/conectori MC4
- Material rama: Aluminiu
Aplicatii: purificare a apei, iluminat, sisteme de iluminat stradal, semnalizare trafic rutier, incarcarea bateriilor, sisteme de supraveghere, statii meteo, etc.
Tip de panou: Policristalin
Putere panou (W): 20 W
Tip Produs: panou policristalin
Tip aparat (componente si sisteme FV): Panou solar
Utilizare: Rezidential|Industrial
Suprafata acoperis: 10 m²
Tipuri de sisteme: Fotovoltaic
-
Fisa tehnica BlueSolar-Polycrystalline-Victron Energy
Descarca
